22.5×8.25 Alcoa Hub-Piloted Commercial Wheel – Heavy-Duty, 10-Hole 285mm Bolt Pattern, Premium High-Polish Finish

Description

Alcoa Part Number: 885657

Wheel Specs:
Finish: High Polish
Position: All Position Wheel (Front, Rear, or Trailer)
Mounting Set Up: Hub Pilot
Wheel Size: 22.5″ x 8.25″
Bolt Pattern: 10×285.75mm
Hub Bore Diameter: 220mm
Hand/Vent Holes: 10
Wheel Outset: 6.6″
Disc Thickness: .89″
Bolt Hole Diameter: 26mm
Weight: 50 Lbs
Max Load & Inflation: 8050lbs @ 130psi
Installed Valve Stem: TR554D
Warranty Info: Warranty for Alcoa Wheels
File Alcoa Warranty: 800-242-9898 Option #1 or Online Claim Form

Replaces Part:

• 885600, 885670, 885607. 885677

Approved Tire Size:

• 255/70R22.5
• 275/8022.5
• 295/75R22.5
• 11R22.5

Typical Applications:
