Alcoa 22.5×9.00 Flat-Face Steer Wheel, Hub-Piloted Design with 10×285mm Bolt Pattern and Mirror-Polished Surface

Description

Alcoa Part Number: 89U631
Wheel Specs:
Finish: Mirror Polish
Position: Front Only
Mounting Set Up: Hub Pilot Dual-Mounting
Wheel Size: 22.5″ x 9.00″
Bolt Pattern: 10×285.75
Hub Bore Diameter: 220mm
Hand/Vent Holes: 10 @ 1.5″
Wheel Outset: N/A
Disc Thickness: N/A
Bolt Hole Diameter: 26mm
Weight: 48 lbs
Max Load & Inflation: 10000lbs @ 130psi
Installed Valve Stem: TR555E

Replaces Part:

•  893651
•  893631

Approved Tire Size:

• 315/80R22.5
• 295/60R22.5
• 12R22.5

Typical Applications:

• Steer Axle for Dump or other Heavy Haul Trucks
