Snow/Light Material Blade
TRACTOR / SMALL SKID STEER
The Snow/Light Material Blade is the perfect way to remove snow from walks, driveways, or parking lots. Use it in the summer for light material grading by engaging the standard locking trip mechanism. Add the optional Wing Kit and your blade becomes a snow pusher, increasing your production of larger areas and lots.
Features
- Dual cylinder’s provide maximum force in angled positions
- Moldboard has four (4) trip springs for component protection and strength.
- Highly visible guide markers for easy location of blade edge
- Easy-adjust depth shoes
- 25° left/right manual angling or optional hydraulic
- Locking trip mechanism comes standard
SPECS
| Model | 72” | 84” | 96” | 108” |
|---|---|---|---|---|
| Part Number | 900341 / 901609 | 900343 / 901610 | 900345 / 901611 | 900347 / 901612 |
| Angling | Manual / Hydraulic | Manual / Hydraulic | Manual / Hydraulic | Manual / Hydraulic |
| Angling | 30° | 30° | 30° | 30° |
| Width | 72” | 84” | 96” | 108” |
| Height | 28.25” | 28.25” | 28.25” | 28.25” |
| Width Fully Angled | 62.75” | 73.25” | 83.75” | 94.25” |
| Trip Type | Moldboard | Moldboard | Moldboard | Moldboard |
| Trip Springs | 4 | 4 | 4 | 4 |
| Cutting Edge | 3/8” x 6” | 3/8” x 6” | 3/8” x 6” | 3/8” X 6” |
| Cylinder | (2) 1.5″ x 8″ | (2) 1.5″ x 8″ | (2) 1.5″ x 8″ | (2) 1.5″ x 8″ |
| Moldboard Thickness | .135” | .135”` | .135” | .135” |
| Mounting Plate | Universal | Universal | Universal | Universal |
| Shipping Weight | 675 lb. | 710 lb. | 745 lb. | 780 lb. |
| Operating Weight | 590 lb. | 625 lb. | 660 lb. | 710 lb. |
| Options | ||||
| Urethane Cutting Edge | ||||
| Rubber Cutting Edge | ||||
| Hardened Skid Shoes | ||||
| Urethane Skid Shoes | ||||
| Wing Kit | ||||
| Factory Installed Couplers |
