Description
DESCRIPTION
Fork Slot Bucket
- Slips over your fork tines.
- It has a high carbon 3/4″ x 6″ cutting edge
- Heavy duty 1-inch diameter pins secure the bucket to your forks.
- It’s ideal for light material, trash, and general site clean up.
- The fork slot bucket is available in 60″, 72″, 96″ and 108″ widths.
____________________________________________________________________________________________________________________________________________________________________________________________
Extended Fork Slot Bucket
- Slips on Fork Tines up to 60″ long
- Standard Pocket size 3 1/2″ x 7 1/2″
- Keeper pins are chained to the Bucket
- 3/4″ x 6″ Weld-on Edge with an optional Bolt-on Edge
- 1/2″ x 3″ Wear Strips
SPECIFICATIONS
Fork Slot Bucket
| Model | Bucket Height | Inside Depth | Bucket Width | Struck Capacity | Weight |
|---|---|---|---|---|---|
| MFSB 60 | 28.0″ | 52.0″ | 60″ | 1.00 cu. yd. | 630 lbs. |
| MFSB 72 | 28.0″ | 52.0″ | 72″ | 1.20 cu. yd. | 675 lbs. |
| MFSB 96 | 28.0″ | 52.0″ | 96″ | 1.60 cu. yd. | 850 lbs. |
| MFSB 108 | 28.0″ | 52.0″ | 108″ | 1.80 cu. yd. | 920 lbs. |
| High Capacity |
|||||
|
MFSB-48H-72 |
38.5″ | 52.0″ | 72″ | 1.6 cu. yd. | 750 lbs. |
| MFSB-48H-96 | 38.5″ | 52.0″ | 96″ | 2.2 cu. yd. | 925 lbs |
| SHC-01 | Add Shurlock Chain and Hook options (2 chains and 2 hooks per bucket) | ||||
Extended Fork Slot Bucket
| Model | Bucket Width | Bucket Height | Bucket Depth | Struck Capacity | Weight |
|---|---|---|---|---|---|
| MFSB 60D-72 | 72″ | 32.5″ | 64.0″ | 2.1 cu. yd. | 825 lbs |
| MFSB 60D-96 | 96″ | 32.5″ | 64.0″ | 2.7 cu. yd. | 1025 lbs |
