Description
DESCRIPTION
5/25
Wheel Xtended Performace Buckets
TAG Xtended Performance Buckets Offer Increased Capacity With Englogated Floors and Curved Extended Profile Sidecutters.
- Includes Bolt on Edge & Rear Wear Pads
- Tooth and Segment Options Available
- Please call for Bolt on Segments, Shanks and Teeth prices
Mountings
Buckets available in direct pin on or with quick coupler adapters
SPECIFICATIONS
| PART # | MOUNTING | BUCKET CAPACITY W/ BOCE | ESTIAMTED WEIGHT |
| P350GP | PIN-ON | 3.50 yd | 2950 LBS |
| QC350GP | QUICK COUPLER | 3.50 yd | 2950 LBS |
| P375GP | PIN-ON | 3.75 yd | 3080 LBS |
| QC375GP | QUICK COUPLER | 3.75 yd | 3080 LBS |
| P400GP | PIN-ON | 4.00 yd | 3200 LBS |
| QC400GP | QUICK COUPLER | 4.00 yd | 3200 LBS |
| P450GP | PIN-ON | 4.50 yd | 3500 LBS |
| QC450GP | QUICK COUPLER | 4.50 yd | 3500 LBS |
| P500GP | PIN-ON | 5.00 yd | 3900 LBS |
| QC500GP | QUICK COUPLER | 5.00 yd | 3900 LBS |
| P550GP | PIN-ON | 5.50 yd | 4300 LBS |
| QC550GP | QUICK COUPLER | 5.50 yd | 4300 LBS |
| P600GP | PIN-ON | 6.00 yd | 4600 LBS |
| QC600GP | QUICK COUPLER | 6.00 yd | 4600 LBS |
| P650GP | PIN-ON | 6.50 yd | 5100 LBS |
| QC650GP | QUICK COUPLER | 6.50 yd | 5100 LBS |
| P700GP | PIN-ON | 7.00 yd | 5600 LBS |
| QC700GP | QUICK COIPLER | 7.00 yd | 5600 LBS |
| P750GP | PIN-ON | 7.50 yd | 6100 LBS |
| QC750GP | QUICK COUPLER | 7.50 yd |
6100 LBS |
| P800GP | PIN-ON | 8.00 yd |
6600 LBS |
| QC800GP | QUICK COUPLER | 8.00 yd |
6600 LBS |
| P900GP | PIN-ON | 9.00 yd |
7650 LBS |
| QC900GP | QUICK COUPLER | 9.00 yd |
7650 LBS |
| P1000GP | PIN-ON | 10.00 yd |
8500 LBS |
| QC1000GP | QUICK COUPLER | 10.00 yd |
8500 LBS |
ADD ONS
ADD WELD-IN (2) BOLT CNC MACHINED CORNERS w/ CAST ALLOY GUARDS
| BKT. CAPACITY | WEIGHT |
| 3.50 – 3.75 yd | 65 LBS |
| 4.00 – 5.00 yd | 85 LBS |
| 5.50 – 6.50 yd | 100 LBS |
| 7.00 – 10.00 yd | 160 LBS |
