Northstar 22.5×9.00 Mirror-Polished Aluminum Wheel – Front Hub Pilot, Flat Face, 10x285mm Bolt Pattern

Description

• Size: 22.5 x 9.00

• Finish: Mirror Polish

• Position: Steer/Lift Axle Only

• Bolt Pattern: 10-Hole Hub Pilot, 285.75mm Bolt Circle, 220mm Center Bore

• Inset: 3.12”

• Max Load: 9900 lbs @ 130 PSI

• Bolt Hole Diameter: 26mm

• Warranty: 5 Year

• Replaces Parts: Alcoa 89U63x, Accuride 41012

• Approved Tire Sizes: 315/80R22.5, 295/60R22.5, 12R22.5

• Typical Applications: Class 8 Trucks (Kenworth, Peterbilt, Freightliner, Volvo, International, Mack, Sterling)

Key Features

• Material and Finish: High-quality mirror polished finish for enhanced durability and appearance.

• Application: Specifically designed for the steer/lift axle position on Class 8 trucks.

• Load Capacity: Capable of supporting up to 9900 lbs at 130 PSI.

• Compatibility: Fits a variety of heavy-duty truck brands including Kenworth, Peterbilt, Freightliner, Volvo, International, Mack, and Sterling.

• Warranty: Comes with a 5-year warranty for added peace of mind.
