Paladin FFC 115 Series Snow Blade for Skid Steer Loaders

Description

DESCRIPTION

12/25

FFC SNOW BLADE

DURABLE, HIGH-PERFORMANCE SNOW REMOVAL FOR SKID STEERS & COMPACT LOADERS

The FFC Snow Blade is built for efficient, heavy-duty snow removal on large skid steers, compact utility loaders, and small wheel loaders equipped with a universal skid steer mount. Designed for versatility and control, this blade features a spring-loaded moldboard trip system and offers 30° (114 Series) or 35° (115 Series) hydraulic angling left or right.

Each unit comes complete with a steel snow blade, universal SSL mount, and hoses and couplers. For lighter dozing work, the included I-bolts can be swapped with the trip springs. CE certification is also available.

---

FEATURES

• 30° (114 Series) or 35° (115 Series) hydraulic angle left/right

• Reversible, replaceable wear edge with optional rubber cutting edge

• Adjustable skid shoes for surface protection

• Spring-loaded moldboard trip mechanism for obstacle impact protection

• Heavy-duty seven-gauge steel blade construction

SPECS

MODEL	11460-0022	11472-0022	11484-0022	11496-0022
WIDTH	60″	72″	84″	96″
WEIGHT	510 LBS	595 LBS	635 LBS	650 LBS
OD HEIGHT	24″	24″	24″	24″
OAL	35″	35″	35″	35″
OAW	60″	72″	84″	96″
SERIES	114	114	114	144
ANGLED WIDTH @ 30 DEGREE

MODEL	11596-0022	11508-0022	11520-0022
WIDTH	96″	108″	120″
WEIGHT	1232 LBS	1309 LBS	1393 LBS
OD HEIGHT	32″	32″	32″
CARRIER LBS	<20000	<20000	<20000
CARRIER LIFT CAP LBS	<11000	<11000	<11000
OAL	58″	58″	58″
OAW	96″	108″	120″
SERIES	115	115	115
ANGLED WIDTH @ 35 DEGREE

BIG DAVE

This blade has been around since the 1990’s tried and true it works just fine.
