Spider Extreme Duty Grapple Rake
Skid Steer Attachment
The Spider Extreme Duty Grapple Rake is built for demanding land clearing, cleanup, and material handling applications. Designed to efficiently rake, gather, and load debris, this rugged attachment makes short work of brush, roots, logs, and construction waste. The curved rake design allows operators to easily roll debris into tight piles or confined areas, increasing productivity on every job.
Constructed from ½″ top-quality steel and engineered for 65 HP and larger machines, the Spider Extreme Duty Grapple Rake delivers the strength and durability required for tough working conditions. Available with either a single grapple or optional dual independent grapples, it provides excellent load control and secure material handling across uneven terrain.
American-made hydraulic cylinders rated at 4,000 PSI ensure reliable clamping force and long service life, even under heavy use. Whether you’re clearing land, cleaning up storm debris, or handling demolition material, this grapple rake is built to perform.
Key Features & Benefits
-
Extreme-duty grapple rake for raking and loading debris
-
Curved rake design rolls material easily into tight or compact areas
-
Available with single grapple or optional dual independent grapples
-
American-made hydraulic cylinders rated at 4,000 PSI
-
Built from ½″ high-strength steel for maximum durability
-
Rated for 65 HP or larger skid steers and compact loaders
- Replaceable teeth
Applications
-
Land clearing and site preparation
-
Brush, root, and log handling
-
Storm and property cleanup
-
Construction and demolition debris removal
The made in the USA Spider Extreme Duty Grapple Rake combines strength, smart design, and dependable hydraulics to deliver reliable performance for professional operators who demand durability and control on every job.
SPECS
| Style | Extreme Duty Grapple Rake |
| Product | SPD-XGR63T |
| Description | X-TREME GRAPPLE RAKE W/ TEETH, 63” |
| Material Thickness | 1/2″ top quality steel |
| Cylinder Size | 2″ x 10″ 4,000 PSI |
| RPM | Recommended for 65 HP and above machines |
| Working Width | 63″ |
| Weight (lbs.) | 824 |
| Notes | 23 Series Teeth Standard and has a full 51″ opening |
| Style | Extreme Duty Grapple Rake |
| Product | SPD-XGR66T |
| Description | X-TREME GRAPPLE RAKE W/ TEETH, 66” |
| Material Thickness | 1/2″ top quality steel |
| Cylinder Size | 2″ x 10″ 4,000 PSI |
| RPM | Recommended for 65 HP and above machines |
| Working Width | 66″ |
| Weight (lbs.) | 863 |
| Notes | 23 Series Teeth Standard and has a full 51″ opening |
| Style | Extreme Duty Grapple Rake |
| Product | SPD-XGR72T |
| Description | X-TREME GRAPPLE RAKE W/ TEETH, 72” |
| Material Thickness | 1/2″ top quality steel |
| Cylinder Size | 2″ x 10″ 4,000 PSI |
| RPM | Recommended for 65 HP and above machines |
| Working Width | 72″ |
| Weight (lbs.) | 942 |
| Notes | 23 Series Teeth Standard and has a full 51″ opening |
| Style | Extreme Duty Grapple Rake |
| Product | SPD-XGR78T |
| Description | X-TREME GRAPPLE RAKE W/ TEETH, 78” |
| Material Thickness | 1/2″ top quality steel |
| Cylinder Size | 2″ x 10″ 4,000 PSI |
| RPM | Recommended for 65 HP and above machines |
| Working Width | 78″ |
| Weight (lbs.) | 954 |
| Notes | 23 Series Teeth Standard and has a full 51″ opening |
| Style | Extreme Duty Grapple Rake |
| Product | SPD-XGR81T |
| Description | X-TREME GRAPPLE RAKE W/ TEETH, 81” |
| Material Thickness | 1/2″ top quality steel |
| Cylinder Size | 2″ x 10″ 4,000 PSI |
| RPM | Recommended for 65 HP and above machines |
| Working Width | 81″ |
| Weight (lbs.) | 1002 |
| Notes | 23 Series Teeth Standard and has a full 51″ opening |
| Style | Extreme Duty Grapple Rake |
| Product | SPD-XGR84T |
| Description | X-TREME GRAPPLE RAKE W/ TEETH, 84” |
| Material Thickness | 1/2″ top quality steel |
| Cylinder Size | 2″ x 10″ 4,000 PSI |
| RPM | Recommended for 65 HP and above machines |
| Working Width | 84″ |
| Weight (lbs.) | 1031 |
| Notes | 23 Series Teeth Standard and has a full 51″ opening |
| Style | Extreme Duty Grapple Rake |
| Product | SPD-XGR96T |
| Description | X-TREME GRAPPLE RAKE W/ TEETH, 96” |
| Material Thickness | 1/2″ top quality steel |
| Cylinder Size | 2″ x 10″ 4,000 PSI |
| RPM | Recommended for 65 HP and above machines |
| Working Width | 96″ |
| Weight (lbs.) | 1099 |
| Notes | 23 Series Teeth Standard and has a full 51″ opening |
