DESCRIPTION
WAIN ROY TILT BUCKETS
Tilt Buckets rotate up to a total of 90 degrees, 45 degrees each side of center, for greater control and flexibility during ditch cleaning, grading, backfilling and loose material loading and unloading applications. The tilting mechanism allows the bucket to rotate at various angles in order to form the surface to the desired shape without repositioning the machine. This is especially beneficial when working along roadways or in tight operating conditions.
45° rotation. Bolt‑on edge standard. Machine must be equipped with valve and lines down to end of dipperstick. Valve must have port reliefs. For Hydraulic Kit availability & pricing, contact Dealer Services.
SPECIFICATIONS
|
TILT BUCKET OEM PIN ON |
WIDTH | CAPACITY (CU. YD.) | LBS |
| TLT3PO-60 | 60″ | 1.00 | 1875 |
| TLT3PO-72 | 72″ | 1.13 | 2400 |
|
TILT BUCKET WAIN ROY XLS / ORIGINAL GANNON / CP / TAG |
WIDTH | CAPACITY (CU. YD.) | LBS |
|
TLT3QC-60 |
60″ | 0.90 | 1322 |
| TLT2QC-72 | 72″ | 1.10 | 1468 |
FITS
| MAKE | MODELS: 15 TON 30,000 – 41,000 LBS |
| CASE |
|
| CAT |
|
| DOOSAN |
|
| HITACHI |
|
| HYUNDIA |
|
| JCB |
|
| JOHN DEERE |
|
| KOBELCO |
|
| KOMATSU |
|
| LIEBHERR |
|
| LINK BELT |
|
| LIUGONG |
|
| MECALAC |
|
| NEW HOLLAND |
|
| TEREX |
|
| VERMEER |
|
| VOLVO |
|
| WACKER NEUSON |
|
