Description

DESCRIPTION

9/25

GENERAL PURPOSE BUCKETS

Recommended Applications

Designed to dig in virgin soil and handle material up to 3,200 lbs./cu. yard in density.

Quality Construction

High-strength, abrasion-resistant steel is utilized in all critical components. Additional reinforcing ensures longer life in more rugged conditions. All seams are welded solid. Each bucket is engineered with tapered side plates to reduce wear on the buckets sides, and to allow for easier dumping.

Cutting Equipment Options

Auxiliary edge and teeth are available upon request.

Standard Sizes

3/4 cu. yd. to 8.0 cu. yds. of various widths are available. Special designs and capacities are available upon request.

Features

• Enhanced High performance Profile
• Designed for general purpose applications with material densities up to 3,200 lb/cy
• Performance side plates & increased roll back angle allow for greater material retention
• 5%+ greater material retention
• Tapered side plates to reduce wear & easier dumping
• integrated spill guard

SPECIFICATIONS

PART #	WIDTH	CAPACITY	WEIGHT
LHG7144700	144″	7.00	7,200
LHG7144800	144″	8.00	8,000
LHG7144900	144″	9.00	9,700
LHG71441000	144″	10.00	10,500

FITS

CLASS 7

CLASS 7 (70,000 – 85,000 LBS)	MODEL
CASE
CAT	988K, 988G
DEVELON
HITACHI	ZW550
HYUNDAI
JCB
JOHN DEERE	944X HI-LIFT, 944K HI-LIFT
KOMATSU	WA600-8
KUBOTA
LIEBHERR
LINK-BELT
NEW HOLLAND
SANY
TAKEUCHI
VOLVO	L350
WACKER NEUSON
YANMAR
