Description

DESCRIPTION

9/25

D-Lock Hydraulic tilt coupler

Available For

Werk-Brau manufactures all attachments to O.E.M. specs for all makes and models of excavators, mini-excavators, and backhoes.

Features

• Automatic front lock – Locks the front pin in the event the rear pin is not secured
• Multi-pin centers, picks up all attachments in the same weight class with the same pin diameter
• Highly visible front lock indicator
• Triple sealed actuator
• Safety system does not rely on gravity
• Dual pin lock – Locks both front and rear pins in the event of loss of engagement force
• Unlock process is designed to release only when the operator intends to do so, in a controlled and safe manner
• Simple yet safe unlock procedure eliminates accidental releases
• Compact design – Improving machine performance
• No greasing or lubrication required
• Only requires four hydraulic lines
• Up to 180 degrees of tilt
• Fully guarded hoses

 Spring Loaded Tilt Coupler

Available For

Werk-Brau manufactures all attachments to O.E.M. specs for all makes and models of excavators, mini-excavators, and backhoes.

Features

• Triple sealed actuator
• Safety system does not rely on gravity
• Spring Loaded manual locking mechanism
• Simple, yet safe unlock procedure eliminates accidental releases
• No greasing or lubrication required
• Only requires two hydraulic lines
• Up to 180 degrees of tilt

 SPECIFICATIONS

PART #	TYPE	STYLE	WEIGHT
TSC080	Manual	Spring Loaded	315
TPP080	Manual	Pull Pin	300
TD080-45	Hydraulic	D-Lock	530
TD080-50	Hydraulic	D-Lock	530
TD080-55	Hydraulic	D-Lock	530
TD080-60	Hydraulic	D-Lock	530
TK080-####-5294	Manual	Kubota KX080 tilt coupler PO top	300
TS080-5294	Manual	Kubota KX080 tilt coupler QC top	300

FITS

Mini 3

MAKE / WEIGHT CLASS	MINI 3 (11,000 – 14,000 LBS.)
BOBCAT	E80, E85
CASE
CAT	306CR
DOOSAN	DX80
DITCH WITCH
GEHL	GE753Z, GE803
HITACHI
HYUNDAI	R75
IHI	55N-2, 55NX, 65NX, 80NX
JCB	8060
JOHN DEERE
KOBELCO
KOMATSU	PC78, PC95, PC88MR-8
KUBOTA
LINK BELT
MUSTANG	8003, 7503ZT
NEW HOLLAND
SANY
TAKEUCHI	HR32
VOLVO
YANMAR
WACKER NEUSON	ET90, EW100, 8003

Mini 4

MAKE / WEIGHT CLASS	MINI 4 (14,000 – 16,000 LBS.)
BOBCAT
CASE	CX75, CX80
CAT	307.5, 308CR, 308CRVAB, 309CR, 309CRVAB
DOOSAN	DX85SR-3
DITCH WITCH
GEHL
HITACHI	ZX75, ZX80
HYUNDAI	R80
IHI
JCB	8080
JOHN DEERE	75G, 85G
KOBELCO	70SR, 75SR, 80CS, SK85
KOMATSU
KUBOTA	KX080
LINK BELT	75, 80
MUSTANG
NEW HOLLAND	E70, E80
SANY	SY75, SY80
TAKEUCHI	TB070, TB175, TB180FR, TB285, TB290
VOLVO	EC70, ECR88
YANMAR	SV100, Vio-70, Vio75-a, Vio-80, B7-5A
WACKER NEUSON

 Mini 5

MAKE / WEIGHT CLASS	MINI 5 (16,000 – 25,000 LBS.)
BOBCAT	7X125
CASE
CAT	310
DOOSAN
DITCH WITCH
GEHL	GE1202
HITACHI	ZX90, ZX100
HYUNDAI
IHI
JCB
JOHN DEERE
KOBELCO
KOMATSU
KUBOTA
LINK BELT
MUSTANG	ME12002
NEW HOLLAND	E90
SANY
TAKEUCHI
VOLVO
YANMAR
WACKER NEUSON
