Description

DESCRIPTION

9/25

D-Lock Hydraulic tilt coupler

Available For

Werk-Brau manufactures all attachments to O.E.M. specs for all makes and models of excavators, mini-excavators, and backhoes.

Features

• Automatic front lock – Locks the front pin in the event the rear pin is not secured
• Multi-pin centers, picks up all attachments in the same weight class with the same pin diameter
• Highly visible front lock indicator
• Triple sealed actuator
• Safety system does not rely on gravity
• Dual pin lock – Locks both front and rear pins in the event of loss of engagement force
• Unlock process is designed to release only when the operator intends to do so, in a controlled and safe manner
• Simple yet safe unlock procedure eliminates accidental releases
• Compact design – Improving machine performance
• No greasing or lubrication required
• Only requires four hydraulic lines
• Up to 180 degrees of tilt
• Fully guarded hoses

 Spring Loaded Tilt Coupler

Available For

Werk-Brau manufactures all attachments to O.E.M. specs for all makes and models of excavators, mini-excavators, and backhoes.

Features

• Triple sealed actuator
• Safety system does not rely on gravity
• Spring Loaded manual locking mechanism
• Simple, yet safe unlock procedure eliminates accidental releases
• No greasing or lubrication required
• Only requires two hydraulic lines
• Up to 180 degrees of tilt

 SPECIFICATIONS

PART #	TYPE	STYLE	WEIGHT
TSC055	Manual	Spring Loaded	220
TPP055	Manual	Pull Pin	200
TD05-45	Hydraulic	D-Lock	375
TS055-####-5306	Manual	Kubota KX057/U55 tilt coupler w/ PO top	200
TS050-5306-5306	Manual	Kubota KX057/U55 tilt coupler w/ QC top	200
TW055-####-5084	Manual	JD 50 Wedge tilt coupler w/ PO top	200
TW055-5084	Manual	JD 50 Wedge tilt coupler w/ QC top	200
TW055-####-5302	Manual	JD 60 Wedge tilt coupler w/ PO top	200
TW055-5302	Manual	JD 60 Wedge tilt coupler w/ QC top	200

FITS

Mini 15

MAKE / WEIGHT CLASS	MINI 15 (7,500 – 11,000 LBS.)
BOBCAT	335, 337, 341, 435, E45, E50, E55, E60
CASE	CX50B, CX55B, CX57C, CX60C
CAT	303.5E2CR, 304E2CR, 304.5E2XTC, 305E2CR, 305.5E2CR
DOOSAN	DX60, DX63-3
DITCH WITCH
GEHL	GE503Z, GE603
HITACHI	ZX50, AX60
HYUNDAI	R55, R60
IHI	40JX, 45JX
JCB	8040, 8045, 8052
JOHN DEERE	50G
KOBELCO	50SR, 55SRX
KOMATSU	PC45MR-3, PC55MR-3, PC58UU-3
KUBOTA	U55, KX057
LINK BELT
MUSTANG	5003ZT, 6003
NEW HOLLAND	E50, E55BX
SANY	SY50, SY60
TAKEUCHI	TB145, TB153FR, TB250, TB260
VOLVO	EC55B, ECR58
YANMAR	Vio55-5
WACKER NEUSON	ET65, EW65, EZ53, 6003

Mini 2

MAKE / WEIGHT CLASS	MINI 2 (7,500 – 11,000 LBS.)
BOBCAT
CASE
CAT
DOOSAN
DITCH WITCH
GEHL
HITACHI
HYUNDAI
IHI
JCB
JOHN DEERE	60G
KOBELCO
KOMATSU
KUBOTA
LINK BELT
MUSTANG
NEW HOLLAND
SANY
TAKEUCHI
VOLVO
YANMAR
WACKER NEUSON
