Description
DESCRIPTION
Revised 11/24
Mini Power Angle Broom
The Mini Power Angle Broom is designed for heavy-duty sweeping of dirt, snow, and other unwanted material. It quickly mounts to your mini skid steer. Featuring a 48” width and optional hydraulic angle change, this attachment is designed to go anywhere to get the job done!
Features
- Direct-drive design
- Power angling (optional)
- Angles 25° to the right and left
- Storage stands come standard
SPECS
| Model | Power Angle Broom Mini | |
| Working Width | 48” | 60″ |
| Working Width @ 25° Angle | 43.5” | 54.4″ |
| Overall Width | 58.5” | 70.4″ |
| Maximum Angle (both ways) | 25° | 25° |
| Bristle Diameter | 24” | 24” |
| Rated Flow | 7-17 GPM | 7-17 GPM |
| Operating psi | 2,000 – 3,000 psi | 2,000 – 3,000 psi |
| Weight | 325 lb. | 385 lb. |
| Mounting Kit Configurations | ASV/Terex (RC/PT30) | ASV/Terex (RC/PT30) |
| Bobcat (MT-52/55, 463/S70) | Bobcat (MT-52/55, 463/S70) | |
| Toro / Vermeer / Boxer / Ditch Witch / Ramrod / Kanga / Cormidi | Toro / Vermeer / Boxer / Ditch Witch / Ramrod / Kanga / Cormidi | |
| Universal Mounting Plate (up to 1,000 lb. ROC and within rated flow) | universal Mounting Plate (up to 1,000 lb. ROC and within rated flow | |
| Options | ||
| Toggle Control Harness* | ||
| Loader Specific Wire Harness* | ||
| Factory Installed Couplers | ||
| Model Description | Part Number | |
| Manual Angling w/poly | 900890 | 901578 |
| Manual Angling w/steel | 901300 | 901580 |
| Manual Angling w/poly/steel | 900891 | 901579 |
| Hydraulic Angling w/poly | 900892 | 901581 |
| Hydraulic Angling w/steel | 901301 | 901583 |
| Hydraulic Angling w/poly/steel | 900893 | 901582 |
| Hydraulic Angling Reversible w/poly | 900888 | 901584 |
| Hydraulic Angling Reversible w/steel | 901302 | 901586 |
| Hydraulic Angling Reversible w/poly/steel | 900889 | 901585 |
| * Applies to hydraulic model only |
