Description
DESCRIPTION
Compact StumpEx
Blade Body:
- Bolts directly to gearbox output shaft
- Abrasion resistant material
- Hexagonal shaft receiver for gearbox output
- Blades can be sharpened to increase longevity
Cone:
- Integrated into body (1 piece unit)
- 3/8” thread pitch
- Max Flow = 20 GPM
- Max Pressure = 3000 psi
- Max Torque = 4000 ft lbs.
- No Case Drain
- Mounts on CUL with mini quick attach plate
- Cuts up to 16” diameter stump in single pass
- 45” overall length from tip to QA plate
BLADE BODY AND CONE
- Blade Body:
- Bolts directly to gearbox output shaft
- Abrasion resistant material
- Hexagonal shaft receiver for gearbox output
- Blades can be sharpened to increase longevity
CONE
- Integrated into body (1 piece unit)
- 3/8” thread pitch
SPECIFICATIONS
| MAX FLOW | 20 GPM |
| MAX PRESSURE | 3000 PSI |
| MAX TORQUE | 4000 FT LB |
| CASE DRAIN | NO |
| MOUNTING | UNIVERSAL (TORO) |
| CUT (UP TO) | 16″ STUMP IN SINGLE PASS |
| LENGTH | 45″ |
COMPAIRISON
|
Toro Dingo Auger Unit |
Fecon Unit |
|
•1,515 ft.-lbs. @15 GPM |
•4,000 ft.-lbs. @15 GPM |
|
•57 RPM @15 GPM |
•27 RPM @15 GPM |
|
•*190 lbs. |
•350 lbs. |
|
•Swinging mount |
•Rigid mount |
