Trench Backfiller Attachment

Designed for time and money-saving efficiency, this attachment lets operators fill trenches in a single pass. Two sets of opposing augers direct the spoils from the sides of the trench back into the hole, while the filler levels off the work area – and fluffs the turf on each side of the trench – minimizing its footprint

14″ (36 cm) Auger Diameter

Enhances productivity with single-pass trench filling.

Integrated Float

Float mechanism allows for up to 5″ ground following and constant flotation, resulting in improved trench cleanup.

Notched Frame

Auger frame is notched in the middle to create mounding that will compact over time, a feature that helps avoid the need for follow-up labor after the ground has settled.

Adjustable Skids

Toro-exclusive adjustable skids help prevent scalping by spreading the weight of the unit over a larger surface area. Skids allow 1-1/4″ (3.2 cm) vertical adjustment depending on ground conditions. Set high for existing turf conditions; set low for exposed soil conditions. The trench filler floats across the ground without digging or sinking in and disrupting turf.

SPECIFICATION

Auger Diameter	14 in. / 35.5 cm
Construction	Fabricated, welded steel frame
Float Distance	5 in. / 12.7 cm
Height	22 in. / 55.8 cm
Length	31 in. / 78.7 cm
Models	Dingo 320-D, Dingo 323, Dingo TX 1000, Dingo TX 1000 TURBO, Dingo TX 1300, Dingo TX 427, Dingo TX 525, Dingo TX 700
Mounting Frame	Dingo® quick-attach mount plate, fabricated, welded base
Quick Couplers	Dripless, flush face quick couplers
Weight	410 lbs / 186 kg
Width	62 in. / 157.5 cm
Working Width	48 in. / 121.9 cm
