SEVERE DUTY DITCHING & GRADING BUCKETS

Recommended Applications

Specifically designed for ditch maintenance and construction. Also useful in grading and slope work.

Construction

T-1 steel is utilized in all high wear components. A rigid top section assures structural stability in the wider sizes. This bucket features a double bottom, side wear guards, and a center rib. Each bucket is engineered with tapered side plates to reduce wear on the buckets sides, and to allow for easier dumping.

Cutting Equipment Options

Teeth are not used on these buckets due to the application.

Standard Sizes

Standard widths range from 48″ – 84″, and capacities of .64 cu. yd. – 4.0 cu. yd.

Additional Features

The Severe duty features all the same features as the standard duty, but is built to handle greater stress. This bucket features a double bottom, side wear guards, and a center rib.

SPECIFICATION

PART #	WIDTH	CAPACITY	WEIGHT
2SDDCG48	48″	0.80	1,650
2SDDCG54	54″	0.90	1,775
2SDDCG60	60″	1.00	1,875
2SDDCG66	66″	1.10	1,975
2SDDCG72	72″	1.30	2,125

FITS

MAKE / WEIGHT CLASS	25MT (50,000 – 59,000 LBS.)
CASE	CX250, CX260E
CAT	325, 326F
DOOSAN	DX255LC-5
HITACHI	ZX240, ZX250
HYUNDAI	HX260
JOHN DEERE	250G, 250P
KOBELCO	SK260LC
KOMATSU	PC240
LIEBHERR	R 916 L, R 924 L, R 934 CD
LINK BELT	250X3, 250X4
SANY	SY235, SY265
TAKEUCHI
VOLVO	EC240, EC250
