KATO 17V5 MINI EXCAVATOR
COMPACT, POWERFUL & PRECISE
The KATO 17V5 Mini Excavator combines zero tail swing performance, increased digging force, and responsive hydraulics in a compact, stable design. With a 10% boost in digging power and a fast-acting 4-pump hydraulic system, the 17V5 is perfect for construction, landscaping, utilities, and tight-space excavation where precision and maneuverability are critical.
Designed for comfort and efficiency, the 17V5 features smooth hydraulic pilot controls, a fuel-efficient Yanmar engine, and an ergonomic operating space. Safety features such as an auto-parking brake and neutral engine-start system prevent operational errors, while the offset boom and strong breakout force allow for precise digging, skimming, and loading in confined areas.
KEY FEATURES & BENEFITS
-
Operating weight: 4,261 lbs
-
Bucket capacity: 1.6 ft³, width: 12″
-
Bucket digging force: 4,842 lbs
-
Swing speed: 8.5 RPM, travel speed (low/high): 1.3 / 2.5 mph
-
Gradeability: 30°, ground pressure: 4.4 psi
-
Offset boom with hydraulic cylinder, boom swing angle: 55° left / 70° right
-
Total hydraulic system flow: 12 GPM, max auxiliary flow: 7 GPM
-
Engine: YANMAR 3TNV74F, 14.1 HP @ 2,300 RPM, fuel tank: 5.8 gal
-
Standard dozer blade: 3’3” x 9.25”, lift/drop: 11.8” / 9”
-
Zero tail swing design for safe operation in tight spaces
The KATO 17V5 Mini Excavator delivers precision, power, and maneuverability in a compact, highly efficient package—ideal for operators working in confined jobsite environments.
SPECS
Specifications
| Bucket Capacity | 1.6 ft3 |
| Bucket Width | 12″ |
| Operating Weight | 4,261 lbs. |
| Transport Weight | 3,924 lbs. |
| Swing Speed | 8.5 rpm |
| Travel Speed (Low/ High) | 1.3 mph / 2.5 mph |
| Gradeability | 30° |
| Ground Pressure | 4.4 psi |
| Bucket Digging Force | 4,842 lbs. |
Engine
| Model | YANMAR 3TNV74F |
| Output Rating | 14.1 hp / 2,300rpm |
| Fuel Tank Capacity | 5.8 gallons |
Boom Swing System
| Type | Offset Boom w/ Hydraulic Cyl. |
| Swing Angle (L / R) | 55° / 70° |
Hydraulic System
| Total Hydraulic System Flow | 12 gpm |
| Max Auxiliary Hydraulic Flow | 7 gpm |
Dozer Blade
| Size | 3’ 3” x 9.25” |
| Lift Above / Drop Below Ground | 11.8” / 9” |
