V40 Skeleton Grapple
Skid Steer Grapple Attachment for Brush, Logs & Debris
The V40 Skeleton Grapple is a heavy-duty skid steer attachment designed for land clearing, brush handling, and material transport. Featuring two independent jaws with separate hydraulic cylinders, this grapple securely clamps uneven or irregular loads while maintaining consistent pressure. Perfect for hauling logs, brush, and debris, the open-sided design increases efficiency on every job.
Key Features:
-
Dual-cylinder, independent grapple arms for secure clamping of uneven loads
-
Open-bottom skeleton design with 8″ tine spacing for dirt sifting and visibility
-
Tines built from single-piece 1/2″ Grade 50 steel for maximum strength
-
Heavy-duty cylinders with NitroSteel® rods for corrosion and dent resistance
-
Greasable 1 1/4″ pins and Teflon®-coated bushings for long-lasting durability
-
Removable bolt-on step with aggressive laser-cut tread for safe cab entry
⚠️ Note: Clearance issue on John Deere® G-Series loaders (330G, 331G, 332G, 333G).
The V40 Skeleton Grapple delivers strength, precision, and reliability—making it one of the best skid steer grapple attachments for brush clearing and material handling.
SPECS
- Recommended loader capacity – Less than 2400 lbs ROC
- Cylinder Bore / Stroke (in) 2.0 / 8.375
- Cylinder Pins / Hinge Pin Diameter (in) 1.25
| Model | 66″ | 72″ | 84″ |
| Overall Width (in) | 67.5 | 73.5 | 85.5 |
| Depth (in) | 36.9 | 36.9 | 36.9 |
| Height: Overall / Bucket (in) | 26.5 / 20.3 | 26.5 / 20.3 | 26.5 / 20.3 |
| Grapple Jaw Opening (in) | 35.2 | 35.2 | 35.2 |
| Number of Tines | 8 | 9 | 10 |
| Space Between Tines | 8.9 | 8.5 | 8.9 |
| Weight (lbs.) | 780 | 815 | 860 |
